Acrycast Clear Acrylic Sheets

Acrycast is a clear acrylic sheet with outstanding strength, stiffness, and optical clarity. Acrylic sheet is easy to fabricate, bonds well with adhesives and solvents, is easy to thermoform, and is suitable for outdoor use.

Acrycast Clear Acrylic Sheets

Specifications

Minimum Operating Temperature
-40°C
Maximum Operating Temperature
80°C
Food Grade
No
Drinking Water Approved
No
Tensile Strength (MPa)
72
Thermal Expansion (µm/m.K)
80
Coefficient of Friction
N/A
Chemical Resistance
Low
Formats Available
Sheet
Acrycast Clear Acrylic Sheets

Request a Quote

Please provide a valid value.
Please provide a valid value.
Please provide a valid value.
Please provide a valid value.
Please provide a valid value.
Please provide a valid value.
Please provide a valid value.
Please select at least one option.

Acrycast data sheet (GP-grade)

PropertyMethodUnitValue
Coefficient of thermal linear expansionASTM D696°C⁻¹8 x 10⁻⁵
Deflection temperature under load 0.45 MPa, edgewise directionISO 75-1°C101
Deflection temperature under load 1.80 MPa, edgewise directionISO 75-1°C92
Tensile strengthISO 527-1MPa72
Elongation at breakISO 527-1%5.0
Flexural strengthISO 178MPa118
Flexural modulusISO 178MPa3210
Charpy impact strengthASTM D256J/m28.6
Rockwell hardnessISO 2039-2HRM95
Surface resistivityASTM D257Ω4 x 10¹⁵
Volume resistivityASTM D257Ω.cm9 x 10¹⁶
Dielectric breakdownASTM D149kV49
Dielectric strengthASTM D149kV/mm16
Specific gravityISO 1183-1.19
Water absorption (23°C, 24h)ISO 62%0.2

The above data are typical laboratory values and are intended to serve as guides only (not guarantee).
